DH800Y836 kWh
DH800Y — Liquid-Cooled Modular ESS (836 kWh)
Fully modular 836 kWh liquid-cooled energy storage — 2H/4H configurations, C3/C5 anti-corrosion, AI-assisted cloud O&M for utility-scale C&I.
Energy
836 kWh
Voltage / Power
Liquid-cooled DC
Cycle Life
≥ 8,000 cycles
Protection
IP55
Expansion
Up to 20 units
- ✓Fully modular design — rapid deployment & service
- ✓2H / 4H system configurations on demand
- ✓C3 / C5 anti-corrosion grades for coastal & industrial sites
- ✓Full-stack safety with millisecond multi-state alerts
- ✓Cloud-side AI-fine-tuned real-time O&M
Full Specifications
Configurations
DH800Y-2H
836 kWh, C3 anti-corrosion, up to 10 units parallel
DH800Y-2H-C5
836 kWh, C5 anti-corrosion, up to 10 units parallel
DH800Y-4H
836 kWh, C3 anti-corrosion, up to 20 units parallel
DH800Y-4H-C5
836 kWh, C5 anti-corrosion, up to 20 units parallel
System
Cooling Method
Fully liquid cooling
Ingress Protection
IP55
Battery Cabinet (W×D×H)
1000 × 2438 × 2350 mm
Electrical Cabinet (W×D×H)
1000 × 2438 × 965 mm
Specifications are subject to change without notice due to continuous product improvement. Confirm final parameters with our sales team for your order.
