AQUAVOLT5.12 kWh
AquaVolt — AC-Coupled Home Storage System
Plug-and-play AC-coupled battery with built-in inverter — retrofits to 99% of existing solar microinverter systems with ≤10 ms UPS-level backup.
Energy
5.12 kWh
Voltage / Power
AC coupled
Cycle Life
≥ 8,000 cycles
Protection
IP65
Expansion
2.5/3.6 kW models
Weight
65 kg
- ✓Plug & play — no solar inverter replacement needed
- ✓Compatible with 99% of microinverters
- ✓UPS-level switchover ≤ 10 ms keeps loads running
- ✓2.5 kW / 3.6 kW AC models (D2.5LAC-5 / D3.6LAC-5)
- ✓Wi-Fi / Bluetooth / LAN / RS485 monitoring
Full Specifications
Battery
Battery Type
LiFePO4
Nominal Battery Energy
5.12 kWh
Nominal Capacity
100 Ah
Cycle Life
≥ 8,000 cycles
Depth of Discharge (DOD)
95%
Performance
Continuous Charge/Discharge Power
2.5 kW (D2.5LAC-5) / 3.6 kW (D3.6LAC-5)
Off-grid Output Power
3,600 W
Peak Off-grid Output
4,000 VA / 4,000 W (1 min)
Transfer Time
≤ 10 ms
Protection Level
IP65
Interface & Physical
Communication
Wi-Fi / Bluetooth / LAN / RS485
Dimensions (W×H×D)
560 × 650 × 185 mm
Net Weight
65 kg
Specifications are subject to change without notice due to continuous product improvement. Confirm final parameters with our sales team for your order.
